Product Introduction：
Single system collar knitting machine, needle bed is integral type or insert type, which is a full-automatic computerized flat knitting machine without comb device. Computerized collar machine adopts high technology computer chip, high quality metal needle bed, advanced technology and stable performance.
Product Parameter
Gauge | 12G/14G/16G |
Size | 52 Inch/66 Inch/72 Inch/ 80 Inch/100 Inch |
Knitting system | Single carriage single system or two systems, double carriage single system or two systems. |
Knitting Speed | Max knitting speed 1.4m/s,32 speed sections controlled by servo motor. |
Stitch Density | 64 density selection range 0-650 controlled by stepping motor,electrical fine adjust technology. |
Roller Device | Device with up-position roller, 24 sections of automatic control with subsection adjustment. |
Protection device | Automatic stopping,device if yarn broken,yarn knot,batching,striking,completion,overload,designated starting and stopping,program error happen. |
Safety device | The protecting cover is equipped with stopping sensor,emergency stopping,power off device,the whole machine cover to reduce noise and dust. |
Data input | Through the U disk,computer connection for direct input of data |
Language choice | Multi language version:support Chinese, English, Arabia and other language,meanwhile according to customer's needs and the required language |
Driving system | Belt drive, AC servo control |
Power off memory | Device advanced CMOS technology, when power off happen, the knitting data and file is saved for restart knitting. |
Dimension | 52Inch: L 2400mm*W 830mm*H 1800mm |
Weight | 52Inch: G.W 500KG, N.W 450KG |
Power | Voltage:AC 220V, Frequency:50HZ/60HZ, Power:0.5KW |
Product details
① Carriage:Maximum speed is 1.4m/s, adjustable according to the width and patterns of knitwear to avoid invalid movement and achieve high efficiency. It also has short circuit protection of electromagnet, current excessive and jam protection of motor.
② Scissors and Lips:When woven products，scissors and clamps work with each other，so it can cut the yarn which connect with fabric but temporarily unused. This can avoid the waste yarn and product damage or because of thread is too long，possible existence of yarn winding and so hazards. Wasted time of hand-cut yarn will be save and increase efficiency，and easier to production management.
③ Cam board:The latest cam board controlled by stepper motor transmission, performance is more stable.
④ Yarn Storage:Positive Yarn Storage could reduce resistance while the yarn is moving, is suitable for fabric with low elasticity and brittleness such as cashmere yarn, rabbit hair yarn and so on in a result to make the products more even and smooth, as well as improve the machine weaving efficiency.
Product application
Product qualification
Package, Deliver, shipping
Our company uses wooden case packing machine to ensure the safety of the machine in long-distance transportation.
FAQ
Q: How do you do about quality control?
A:Quality is above everything.We always attach great importance to quality controlling from the beginning to the end.Each products are tested one by one which must be in accordance with the factory quality standard before arranged to packing.
Q.What if I receive products I am not satisfied with?
A: We aren't happy unless you are!. If something is not up to your standards - please let us know! We will do everything in our power to make it right. Also, please refer to our Return policy, leave message below, we will send the policy to you soon.
Q: How do I purchase your goods?
A: Please send us inquiry via website, email us, or add friend on WeChat ,Whatsapp through mobile no. and you can also give us a call to tell us your needs, we’ll reply you ASAP.
Q:What if I receive products I am not satisfied with?
A: We aren't happy unless you are!. If something is not up to your standards - please let us know! We will do everything in our power to make it right. Also, please refer to our Return policy, leave message below, we will send the policy to you soon.
Q:Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
